Analog HD CCTV
5 MP Turbo HD cameras over the coax already in your walls, recorded on a hybrid XVR that will still accept IP cameras in three years — installed by our own engineers, with twelve months of AMC included.
Capture
HD analog camera
Transmit
Existing coax
Record
Local DVR / XVR
over the cable already in the wall
5 MP
per camera run, video and power
90 m
installed, two cameras
From ₹10,000
free AMC included
12 months
Modern HD-over-coax carries 5 MP down ordinary 3+1 cable, and on the buildings below it beats an IP system on cost and simplicity at once. On the ones after it, it does not — and we will say so.
HD-over-coax runs 2 MP or 5 MP down the RG59 an older system left behind. Reusing it removes the single most expensive and disruptive part of an upgrade — pulling fresh cable through an occupied building.
Four cameras on a shopfront that will still be four cameras in five years. What IP really buys is cheap change later — another camera, another branch, a new position — and on a system that never changes, that advantage is never spent while the price difference is real on day one.
A DVR you never connect to a router has no remote attack surface at all. For a site where that matters more than viewing from a phone, that is a feature and not a limitation.
No IP addressing, no VLAN, no PoE budget. A camera is a BNC connector and a power lead, and a replacement unit goes back on the wall without anyone touching a network configuration.
5 MP is the practical ceiling on coax. Where identification matters — counters, gates, dock doors — 8 MP with digital zoom holds detail this cannot.
On-camera human and vehicle classification, line crossing and intrusion zones are IP features. Analog gives you pixel-change motion detection, which is a different and much noisier thing.
If nothing is in the walls yet, CAT6 costs about the same to pull as 3+1 and reaches a little further. Everything it enables — 8 MP, on-camera analytics, adding a camera by adding a switch port — comes free with the choice. There is no saving in choosing coax for a building being wired today.
TVI, CVI and AHD all reach 5 MP over the same cable and the same connectors. The difference never shows up at the camera — it shows up three years later, when the recorder decides which replacement cameras you are allowed to buy.
| Format | Comes from | What it gives you |
|---|---|---|
| HDTVI | Hikvision, Prama | Up to 5 MP (8 MP on current recorders) and the longest practical cable runs of the three HD formats. |
| HDCVI | Dahua, CP Plus | Up to 5 MP, with audio and control data carried on the same coax as the video — no second run for a microphone. |
| AHD | Open, many brands | Up to 5 MP and the widest choice of camera suppliers, which keeps replacement units cheap and easy to source. |
| CVBS | Legacy analog | The 960H standard-definition format being replaced. Modern recorders still accept it, so old cameras keep working while you swap them. |
We quote a penta-brid recorder as standard — one that accepts all four formats plus IP. It costs a little more today and it is the difference between adding a camera in three years and replacing the recorder to do it.
HD cameras and a new recorder on the existing RG59. The fastest and cheapest real upgrade there is — a standard-definition system becomes 2 MP or 5 MP in a day, with no new cable and no wall damage.
A penta-brid recorder takes TVI, CVI, AHD, CVBS and IP cameras at once. Your coax cameras stay where they are and IP units go in one at a time on CAT6, at the positions that genuinely need 8 MP.
Ethernet-over-coax converters put a full IP camera on an existing RG59 run. It costs more per camera than either option above, and it is the right answer when the cable route physically cannot be redone.
Most CCTV quotes price the cameras and hide everything that decides whether the picture still holds in year five. These are the four things we specify, and they all appear on the paper you get.
2 MP covers general coverage comfortably; 5 MP Turbo HD goes where detail is worth paying for. Chosen per position during the survey, along with fixed or varifocal lenses and the IR range each mounting height actually needs.
One 3+1 run per camera — a single jacket carrying the coaxial video core and three copper cores for power. The honest difference from PoE is not the number of cables but where the power starts: at a central SMPS rather than the recorder, and a badly earthed supply leg is the most common cause of a picture that rolls.
We fit a penta-brid recorder by default, even on an all-analog system. It costs a little more today and it is the difference between adding an IP camera in three years and replacing the recorder to do it.
Connect the recorder to your router and you get live view, playback and push alerts on a phone over the manufacturer's encrypted cloud. Leave it disconnected and the system records exactly the same. It is a decision, not a default.
The body is a coverage decision, not a taste one. A varifocal unit in a corridor can be tuned to the view after it is on the wall; a fixed dome in the same place is whatever angle it shipped with.
Gates, perimeters, parking. Visible deterrent, IR to 40 m.
Indoor ceilings. Discreet, vandal-resistant IK10 casing.
2.8–12 mm lens, tuned to the view after it is mounted.
Counters, entrances and tills where detail earns its cost.
Warm-light sensors that keep colour after dark, not grey IR.
Reachable positions — metal housings, concealed cable entry.
Resolution buys detail and spends retention. This is what one 2 TB surveillance drive — the size most analog systems ship with — gives you recording around the clock in H.265+.
| Resolution | Per camera | 4 cameras | 8 cameras | 16 cameras |
|---|---|---|---|---|
| 2 MP · 1080p | ~16 GB/day | 28 days | 14 days | 7 days |
| 5 MP · Turbo HD | ~40 GB/day | 11 days | 5 days | 3 days |
Doubling the disk doubles the days, and motion-triggered recording stretches every figure above by roughly two and a half to three times — usually the cheaper route to a 30-day retention target than buying a bigger drive. Tell us the number of days you need to keep and we will size the storage to it.
Hardware, coaxial cabling, labour and the twelve-month AMC — everything except a long run or a scaffold, which is exactly why the survey comes before the number.
4-channel DVR, 1 TB, entrance and one interior view
1 BHK, small shop, single entrance
₹8,000 – ₹16,000
4-channel DVR, 1 TB, up to ~150 m of cable in total
Independent house, retail store
₹15,000 – ₹22,000
8-channel XVR, 2 TB, varifocal at key positions
Showroom, office floor, large villa
₹26,000 – ₹45,000
16-channel XVR, 4 TB+, mixed coax and IP
Apartment block, godown, small campus
₹60,000 – ₹1,00,000
Bands, not quotes. An upgrade that reuses sound coax lands at the bottom of its band; a fresh installation with concealed runs through a finished building lands at the top. The full Chennai price list breaks the components down line by line.
The hardware barely changes between these. What changes is the camera count, where the 5 MP units go, and whether the recorder ever gets plugged into a router.
Four to eight cameras is normally a single day on site, and an upgrade that reuses existing coax is often quicker than that. Sixteen with fresh cabling is two to three days.
01
A technician walks the site, marks blind spots and measures the runs. Where an old system exists we test the coax that is already there and tell you whether it can be reused.
02
Camera positions, resolutions, lens choices, recorder and disk sized against a retention target, and an itemised price — in writing, within 24 hours of the survey.
03
3+1 cable in conduit, run inside 90 m per camera, with a properly earthed supply from a central SMPS, clipped, concealed and labelled. This is what separates a picture that holds from one that rolls in year two.
04
Mount, aim and focus every camera, set varifocal lenses to the actual view, then configure the recorder, schedules, motion zones and — if you want it — the mobile app.
05
Every channel recorded, played back and exported in front of you, day and night footage checked, and whoever needs to pull a clip shown how to do it.
06
Cover starts the day the system goes live — preventive visits, lens cleaning and re-aiming, firmware updates and repairs, priced into the original quote.
Cover starts the day the system goes live and is priced into the quote you are given, not raised as a renewal six months later.
A technician walks your site, tests any cabling that is already there, tells you what can be reused and what the whole thing will cost — in writing, within 24 hours. No obligation attached to any of it.
